RT-01 Rotating Spray Nozzle

Rotating Spray Nozzle is one of the important tools used to improve cleaning efficiency and broaden cleaning scenarios in the modern cleaning field. Compared with traditional connectors, Rotating Spray Nozzle has a wider range of adaptability, which is both labor-saving and safe.

Genuinsky's RT-01 Rotating Spray Nozzle is widely used in industrial equipment cleaning, agricultural cleaning, or municipal and public facilities cleaning scenarios. The Rotating Spray Nozzle has significant advantages from material selection to design details. First of all, let's introduce the working principle of RT-01 Rotating Spray Nozzle. The product mainly achieves physical cleaning through high-speed rotating high-pressure water flow to the surface of the object that needs to be cleaned. After the joint is connected to the suitable high-pressure pump, the water flow enters the internal drive component of the nozzle and runs at high speed, which can form a 360° rotating jet without dead angle, which is converted into a strong high-pressure water flow, which can quickly remove stubborn stains such as oil, rust or mud on the surface of the object. This cleaning method does not need to rely on chemical detergents. It is only cleaned by physical water flow. It is suitable for fields with strict requirements for cleaning media, such as food processing or precision equipment processing.

Secondly, from the performance parameters of RT-01 Rotating Spray Nozzle, the working pressure can withstand up to 7250PSI (about 50MPa). In high-pressure cleaning work, it can be used with a high-power high-pressure pump, and it can also be used for heavy oil stains or hardened rust. Realize efficient peeling work, so that the cleaning effect is in place in one step. The rated flow rate can reach 4.71GPM (about 17.83L/min). This large-flow jet means that it can quickly cover a large area of cleaning areas, which significantly improves cleaning efficiency and saves working time.

Finally, from the material, the component body of this RT-01 Rotating Spray Nozzle is integrally molded with high-quality cast steel. The cast steel material has excellent corrosion resistance. Even if it is in contact with oil pollution in the chemical field for a long time, or chemical media such as acid and alkali, it is not easy to be corroded. Deformation. At the same time, this process is molded through one-time pouring, which means the disappearance of the splicing gap, which greatly improves the structural integrity of the nozzle body. Basically, it can stably withstand the high pressure of 50MPa. In the long-term high-pressure cleaning work, it avoids the risk of leakage caused by cracking, and can adapt to industrial-grade strong high-pressure cleaning. Clean the field. Compared with the traditional spliced metal nozzle, the durability has been greatly improved. The interior adopts high-quality ceramic nozzles and ceramic nozzle seats. The hardness of ceramic material is much higher than that of ordinary metal. Therefore, the aperture accuracy of the nozzle can be maintained for a long time, the precise injection angle of high-pressure water flow can be maintained, and the wear caused by the washing of water flow can be avoided, which affects the cleaning effect, which also significantly improves the service life of the product. .

In order to ensure the safety and stability of the operation and equipment, there are a few tips when using RT-01 Rotating Spray Nozzle. First, avoid pointing the nozzle at people or animals. During use, the operator must wear earplugs, goggles, and protective clothing to avoid accidental injury. Second, daily maintenance and timely cleaning of the dirt at the nozzle after use can avoid blockage during work. If it is not used, the water should be wiped dry to avoid corrosion of the product and affecting the service life.Third, with suitable equipment, the pressure of the pump body is not enough to affect the cleaning effect, and the pressure overload will damage the nozzle.NINGBO GENUINSKY Company is a company specializing in the production of high-pressure cleaning accessories. The company integrates manufacturing, development and sales, with thoughtful after-sales service, excellent quality and preferential price. You can rest assured to use it.
